Wheel Shaped Load Cell Force Load Cell 200KN
Capacity:200KN
Material: Steel Alloy
Dimension:φ206*42mm
Rated Output:4-20mA
Protection Class:IP67/IP68
The BNQ18 is a customizable designed spoke type load cell, bigger dimension, Steel alloy wheel shaped load cell for a higher capacity range for Industrial Scale load cell, Batching scale load cell, Boat Scale load cell with waterproof connector to guarantee stable quality of performance.
Usage & Applications：
Injection moulding machine
BNQ18 Specification：
|
Rated Capacities |
200kN |
|
Rated Output |
4～20mA |
|
Zero Balance |
±0.1%FSR |
|
Non-linearity |
±0.6%FSR |
|
Hysteresis |
±0.6%FSR |
|
Repeatability |
±0.6%FSR |
|
30mins Creep |
|
|
30mins Return |
|
|
Safe Overload |
200%FSR |
|
Ultimate Overload |
|
|
Temperature Effect On Output |
±0.1%FSR/10℃ |
|
Temperature Effect On Zero |
±0.1%FSR/10℃ |
|
Input Impedance |
|
|
Output Impedance |
|
|
Insulation Impedance |
≥2000MΩ |
|
Recommended Excitation |
DC15V～18V |
|
Maximum Excitation |
|
|
OperatingTemperatureRange |
-30℃～70 ℃ |
|
Construction |
Steel Alloy |
|
Protection Class |
IP67 / IP68 |
|
Cable |
φ7×1m(removable cable) |
|
Recommended Platform Size |
|
|
Mode of Connection |
