WD-1201M-DIN(V3)
PRODUCT FEATURES
● Support HomeplugAV2 Protocol standard
● Industrial DIN rail style installation
● The maximum transfer distance up to 500 meters
● Self-adapt the rate
● Quality of Service (QoS)
● IGMO (IPv4) Snooping & MLD (IPv6) Snooping
● Working temperature: -40℃-80℃
● Operating humidity: 10%-85% no condense
● Storage humidity:5%-90% no condense
● Packet loss：≤0.1%（100M,load 70%）
● Support 7*24 hours all weather operation
● Hardware watch dog function
● PING≤20MS
PRODUCT PARAMETERS
| Model | WD-1201M-DIN(V3) |
| Interface |
1*LAN
10/100/1000Base-TX self
adaption RJ45，1*AC power
interface
|
| LED display light | Ethernet, PLC ,Power |
| Transfer frequency | 2-68MHz MIMO |
| Protocol (PHY) | IEEE802.3 ， IEEE802.3x, IEEE802.3u HomeplugAV2 |
| Security | 128-AES |
| Number of each group | Up to 63 |
| installation | Rail TS35 |
| Protection level | IP40 |
| Modulation | OFDM |
| Effective transfer rate | TCP/IP 500Mbps |
| Manageability |
802.1D Ethernet Bridge
Quality of Service(QoS)
IGMO (IPv4) Snooping & MLD
(IPv6) Snooping
|
| Voltage range |
AC 90V-530V 50/60Hz
/DC100-700V /80mA
|
|
Operating temperature
|
-40℃-85℃ |
| Size | 123*97*47(mm)（L×W×H） |
| Weight | 0.25kg |
|
Operating environment
|
Operating
humidity:10%-85%(no
condense)
Storage humidity: 5%-90%(no
condense)
|
| Certification | FCC, CE class B, RoHS |
All specifications are subject to change without prior notice
ANTI-INTERFERENCE
Immunity of ESD
The testing voltage which the device should be
beared: ±6kV direct Discharge, ±8kV air discharge. Discharge number in Each sensitive testing point:
Plus-n-Minus 10 times each, Every time the discharge
interval is 1 s, according to B/T 17626.2-2006.
Immunity of electrical fast transient impulse group
(Common mode)
The testing voltage which the device should be beared:
between the power supply voltage port and ground:
±2.0kV;
between signal circuit and ground: ±1.0kV;
repetition frequency: 5KHz, test duration: 1 min/ time;
testing times: Plus-n-Minus 5 times each. According to
GB/T 17626.4-2008.
Anti interference of surge impact
The testing voltage which the device should be
beared: ±2kV;
The interval of continuous impulses: 1min/time;
Test number: Plus-n-Minus 5 times each. According
to GB/T 17626.5-2008.(protection: all models
protection and varistor series of
discharge tube type).
