Wafer Type Butterfly Valve
Product Video
Product Description
Dimensions:
- Size : DN 50 to DN 600
- Ends : ANSI150/PN10/PN16/JIS10K
Specifications:
- Type of valve: Butterfly valve wafer type
- Working temperature: EPDM -10℃-+120℃
- Face to Face: ISO5752 sequence
- Upper flange standard: ISO5211
- Pressure test conform: API598
- Medium: Fresh Water, Sea Water, Food Stuff, all kinds of oil etc.
Materials :
- Body: GGG-50 ductile iron body allows installation in ANSI 150 and DIN PN 10/16 pipe flanges.
- Disc: Stainless steel 304 (CF8).
- Seat: EPDM body seat
- Stem seal with O-ring EPDM
- Coating: Epoxy coated RAL 5005 – Ductile iron epoxy coated disc +/- 40 µ from DN125 to 300, ductile iron epoxy coated disc +/- 300 µ over for 1150
Product parameter
| NO. | Part | Material |
| 1 | Circlip | 65MN |
| 2 | Lock Piece | Steel |
| 3 | Sleeve | PTFE |
| 4 | O-ring | NBR |
| 5 | Shaft | SS304 |
| 6 | Body | GG25/GGG40 |
| 7 | Seat ring | NBR/EPDM |
| 8 | Disc | GGG40/Stainless steel |
| 9 | Shaft | SS304 |
| 10 | Screw | Steel |
| SIZE | 2″ | 2 1/2″ | 3″ | 4″ | 5″ | 6″ | 8″ | 10″ | 12″ |
| ΦD | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 125 | 125 |
| ΦF | 70 | 70 | 70 | 70 | 70 | 70 | 70 | 102 | 102 |
| 4-Φ2 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 11.5 | 11.5 |
| L | 42 | 44 | 48 | 52 | 56 | 56 | 60 | 68 | 78 |
| □a×a | 9×9 | 9×9 | 11×11 | 12×12 | 14×14 | 14×14 | 17×17 | 20×20 | 22×22 |
Product show
