Tech. Drop Dielectric Cable
Fiber Cont.
1
Outer Diameter (mm)
5.4*3.0（±0.2）
Sheath thickness (mm)
≥0.5
Weight (kg/km)
15
Tensile strength (N)
(Long/short term)
400/1000
Crush (N/10cm)
(Long/short term)
1000/2200
Attenuation
@1310nm
≤0.40dB/km
@1383nm
≤0.35 dB/km
@1550nm
≤0.28 dB/km
Fiber Cont.
1
Outer Diameter (mm)
5.4*3.0（±0.2）
Sheath thickness (mm)
≥0.5
Weight (kg/km)
15
Tensile strength (N)
(Long/short term)
400/1000
Crush (N/10cm)
(Long/short term)
1000/2200
Attenuation
@1310nm
≤0.40dB/km
@1383nm
≤0.35 dB/km
@1550nm
Temperature range
Minimum bending radius
Storage temperature
-40~+70℃
Static
15H
Installation temperature
-40~+70℃
Dynamic
30H
Temperature range
Minimum bending radius
Storage temperature
-40~+70℃
Static
15H
Installation temperature
-40~+70℃
Dynamic
30H
Test items
Testing requirements
Test standard
Tensile strength
IEC 60794-1-21, E1
500/1000, 10min
Additional attenuation≤0.4dB/km, @1550nm
Crush
IEC 60794-1-21, E3
1000/2200 /10cm, 5min
Additional attenuation≤0.4dB/km, @1550nm
Impact
IEC 60794-1-21, E4
1J, R=12.5mm，1 point 1 time
Additional attenuation≤0.4dB/km, @1550nm
Repeat bending
IEC 60794-1-21, E6
R=30H
Additional attenuation≤0.4dB/km, @1550nm
Temperature cycle
IEC 60794-1-22, F1
-40~+70℃,8h,2 cycles
Additional attenuation≤0.4dB/km, @1550nm
Test items
Testing requirements
Test standard
Tensile strength
IEC 60794-1-21, E1
500/1000, 10min
Additional attenuation≤0.4dB/km, @1550nm
Crush
IEC 60794-1-21, E3
1000/2200 /10cm, 5min
Additional attenuation≤0.4dB/km, @1550nm
Impact
IEC 60794-1-21, E4
1J, R=12.5mm，1 point 1 time
Additional attenuation≤0.4dB/km, @1550nm
Repeat bending
IEC 60794-1-21, E6
R=30H
Additional attenuation≤0.4dB/km, @1550nm
Temperature cycle
IEC 60794-1-22, F1
-40~+70℃,8h,2 cycles
Additional attenuation≤0.4dB/km, @1550nm
