S/SH type dual-suction Large flow irrigation and drainage centrifugal pump
S/SH Type Dual-Suction Large Flow Irrigation And Drainage Centrifugal Pump
S, SH single -grade dual -suction cardiac pump is a new energy -saving horizontal inter -pump, which is used to transport other liquids similar to water or psical chemical properties similar to water. According to user needs, it can be used by changing the pump structure and material to transport multi -mud sand or water or material. Various types of corrosive liquids, this series of pumps are suitable for factories, mines, cities, drainage, power stations, farmland irrigation and various water conservancy projects.
S/SH type dual-suction Large flow irrigation and drainage centrifugal pump characteristics:
1. Double -sucking impeller, large flow and high efficiency.
2. Energy saving, wide application range, long life.
3. Convenient maintenance, no need to disassemble the water inlet, outlet pipe roads and motors.
4. The selected mechanical sealing and filling are sealed and the cooling lubrication is internal circulation.
S/SH type dual-suction Large flow irrigation and drainage centrifugal pump application
S, SH single -stage dual -absorbing centrifugal pumps are suitable for factories, mines, cities, drainage, power stations, farmland irrigation and various water conservancy projects.
S/SH type dual-suction Large flow irrigation and drainage centrifugal pump technical data:
| Model |
Capacity
(m3/h) |
Head
(m) |
Speed
(r/min) |
Power (kw)
|
Efficiency
(%) |
NPSH
(m) |
|
|
Shaft power
|
Motor power
|
||||||
|
150S-78
|
160
|
78
|
2950
|
45
|
55
|
75.5
|
3.7
|
|
150S-78A
|
144
|
62
|
2950
|
33.4
|
45
|
72.6
|
3.7
|
|
150S-50
|
160
|
50
|
2950
|
27.3
|
37
|
80.4
|
3.9
|
|
150S-50A
|
144
|
40
|
2950
|
20.0
|
30
|
75.5
|
3.9
|
|
150S-50B
|
133
|
36
|
2950
|
18.0
|
22
|
72.5
|
3.9
|
|
200S-95
|
280
|
95
|
2950
|
91.4
|
132
|
79.2
|
5.3
|
|
200S-95A
|
270
|
85
|
2950
|
83.3
|
110
|
75
|
5.3
|
|
200S-95B
|
260
|
75
|
2950
|
73.8
|
90
|
72
|
5.3
|
|
200S-63
|
280
|
63
|
2950
|
58.3
|
75
|
82.7
|
5.8
|
|
200S-63A
|
270
|
46
|
2950
|
45.1
|
55
|
75
|
5.8
|
|
200S-42
|
280
|
42
|
2950
|
38.1
|
45
|
84.2
|
6
|
|
200S-42A
|
270
|
36
|
2950
|
33.1
|
37
|
80
|
6
|
|
250S-65
|
485
|
65
|
1450
|
109.2
|
132
|
78.6
|
3.1
|
|
250S-65A
|
420
|
48
|
1450
|
88.5
|
90
|
77.7
|
3.1
|
|
2520S-39
|
485
|
39
|
1450
|
61.5
|
75
|
83.6
|
3.2
|
|
250S-39A
|
468
|
30
|
1450
|
48.4
|
55
|
79
|
3.2
|
|
250S-24
|
485
|
24
|
1450
|
36.9
|
45
|
85.8
|
3.5
|
|
250S-24A
|
414
|
20
|
1450
|
27.2
|
37
|
83.3
|
3.5
|
|
250S-14
|
485
|
14
|
1450
|
21.5
|
30
|
85.8
|
3.8
|
|
250S-14A
|
432
|
11
|
1450
|
15.2
|
18.5
|
82.7
|
3.8
|
|
300S-90
|
790
|
90
|
1450
|
243
|
320
|
79.6
|
4.2
|
|
300S-90A
|
756
|
78
|
1450
|
216.4
|
280
|
74.2
|
4.2
|
|
300S-90B
|
720
|
67
|
1450
|
180
|
220
|
73
|
4.2
|
|
300S-58
|
790
|
58
|
1450
|
147.9
|
200
|
84.2
|
4.4
|
|
300S-58A
|
720
|
49
|
1450
|
118.0
|
160
|
82.5
|
4.4
|
|
300S-58B
|
684
|
43
|
1450
|
100
|
132
|
80
|
4.4
|
|
300S-32
|
790
|
32
|
1450
|
79
|
90
|
86.8
|
4.6
|
|
300S-32A
|
720
|
26
|
1450
|
60.7
|
75
|
84
|
4.6
|
|
300S-19
|
790
|
19
|
1450
|
47.1
|
55
|
86.8
|
5.2
|
|
300S-19A
|
720
|
16
|
1450
|
39.2
|
45
|
80
|
5.2
|
|
300S-12
|
790
|
12
|
1450
|
30.4
|
37
|
84.8
|
5.5
|
|
300S-12A
|
684
|
10
|
1450
|
23.9
|
30
|
78.4
|
5.5
|
|
350S-125
|
1260
|
125
|
1450
|
533
|
680
|
80.5
|
5.4
|
|
350S-125A
|
1181
|
112
|
1450
|
461
|
570
|
78.2
|
5.4
|
|
350S-125B
|
1098
|
96
|
1450
|
373
|
500
|
77
|
5.4
|
|
350S-75
|
1260
|
75
|
1450
|
303
|
360
|
85.2
|
5.8
|
|
350S-75A
|
1170
|
65
|
1450
|
244.4
|
280
|
84.2
|
5.8
|
|
350S-75B
|
1080
|
55
|
1450
|
196.3
|
220
|
82.4
|
5.8
|
|
350S-44
|
1260
|
44
|
1450
|
172.5
|
220
|
87.5
|
6.3
|
|
350S-44A
|
1116
|
36
|
1450
|
129.5
|
160
|
84.5
|
6.3
|
|
350S-26
|
1260
|
26
|
1450
|
102
|
132
|
87.5
|
6.7
|
|
350S-26A
|
1116
|
21
|
1450
|
76.9
|
90
|
83.4
|
6.7
|
|
350S-16
|
1260
|
16
|
1450
|
64.4
|
75
|
85.4
|
7.1
|
|
350S-16A
|
1044
|
13
|
1450
|
47
|
55
|
78.3
|
7.1
|
|
500S-98
|
2020
|
98
|
970
|
678.1
|
800
|
79.5
|
4.1
|
|
500S-98A
|
1872
|
83
|
970
|
539
|
630
|
78.5
|
4.1
|
|
500S-98B
|
1746
|
74
|
970
|
450.1
|
560
|
78.7
|
4.1
|
|
500S-59
|
2020
|
59
|
970
|
388.2
|
450
|
83.6
|
4.5
|
|
500S-59A
|
1872
|
49
|
970
|
332.32
|
400
|
75.6
|
4.5
|
|
500S-59B
|
1746
|
40
|
970
|
255.8
|
315
|
74
|
4.5
|
|
500S-35
|
2020
|
35
|
970
|
218.2
|
280
|
83.6
|
4.8
|
|
500S-35A
|
1746
|
27
|
970
|
150.6
|
220
|
75.6
|
4.8
|
|
500S-22
|
2020
|
22
|
970
|
143.6
|
185
|
74
|
5.2
|
|
500S-22A
|
1746
|
17
|
970
|
100.6
|
132
|
88.2
|
5.2
|
|
500S-13
|
2020
|
13
|
970
|
85.7
|
110
|
85.2
|
5.7
|
|
600S-75
|
3170
|
75
|
970
|
736
|
900
|
88
|
6
|
|
600S-75A
|
2920
|
65
|
970
|
600.2
|
710
|
89
|
6
|
|
600S-47
|
3170
|
47
|
970
|
456
|
560
|
87
|
6.5
|
|
600S-32
|
3170
|
32
|
970
|
310.4
|
355
|
83.4
|
7
|
|
600S-32A
|
2850
|
26
|
970
|
229
|
280
|
88
|
7
|
|
600S-32B
|
2620
|
22
|
970
|
229
|
280
|
88
|
7
|
|
600S-22
|
3170
|
22
|
970
|
215.8
|
250
|
84.2
|
7
|
