Outdoor CPE AP 150Mbps 2.4G 500M Wifi Range Long distance
Feature
- Apply IEEE802.11b/802.11g/802.11n/802.3/802.3u
- Transmitted power ：802.11b 19dBm±2dBm，802.11g 15dBm±2dBm，802.11n 13dBm±2dBm
- 2 Port 10/100Mbps Ethernet port,support（Auto MDI/MDIX）
- Support RESET
- Many kinds of way to protect your data transmission
| Hardware | |
|
Main chipset |
AR9331 |
|
RAM |
DDR2 64MB （MAX DDR2 128MB） |
|
FLASH |
SPI 8MB（MAX 16MB） |
|
Protocol |
IEEE802.11b/802.11g/802.11n/802.3/802.3u |
|
Wireless rate |
2.4g 150Mbps |
|
Work frequency |
2.4GHZ |
|
Antennas |
1* Directional antenna |
|
Port |
2*10/100M Ethernet port, support Auto MDI/MDIX |
|
LED |
Power, 1WAN, 1LAN, four signal led lights |
|
Button |
1*Reset |
|
Power adapter |
Non-standard POE 15V/1A |
|
Max Power consumption |
< 5W |
|
Size（L*W*H）&Color |
Size:141*85*26MMColor:Plastic white |
| Others | |
|
Work Environments |
Operating Temperature：0℃ ~ 40℃； Storage Temperature：-40℃~ 70℃；Operating Humidity：10%~90% non-condensing Storage Humidity：10%~90% non-condensing |
