Ø300mm Digital Vertical Profile Projector VP300 Series
Product picture
Vertical Profile Projector Features
● The lifting system adopts cross roller rail and precision screw drive, which makes lifting drive more comfortable and stable;
● With coating process reflector, clearer image and great dustproof;
● Adjustable contour and surface illumination, to meet with difference workpiece demand;
● Imported high light and long using life LED illumination ,to ensure precision measurement demand;
● High resolution optical system with clear image and magnification error is less than 0.08%;
● Powerful Bi-axial fan cooling system，highly increase using life;
● Powerful and colorful DRO DP400，realized fast and accurate 2D Measurement;
● Built-in Mini-printer, can print and save data;
● With standard 10X objective, optional 20X，50X objective，rotary table, foot switch ,clamp, etc.
Projector Specification
|
Product Name |
Ø300mm Digital Vertical Profile Projector |
||
|
Reverse Image |
VP300-1510 (#511-330) |
VP300-2010 (#511-340) |
|
|
Obverse Image |
VP300-1510Z(#511-330Z) |
VP300-2010Z(#511-340Z) |
|
|
Metal Stage Size |
258x308mm |
258x358mm |
|
|
Glass Stage Size |
148x206mm |
148x256mm |
|
|
Stage Travel |
150x100mm |
200x100mm |
|
|
Product Dimension(L×W×H) |
988x563x1224mm |
988x563x1224mm |
|
|
Packing Dimension(L×W×H) |
1200x800x1580mm |
1200x800x1580mm |
|
|
Focusing |
100mm |
||
|
Accuracy |
≤3+L/200(um) |
||
|
Resolution |
0.0005mm |
||
|
Load Capacity |
10Kg |
||
|
Screen |
Dia:φ312mm,Measurement Range ≥ Ø300 |
||
|
Rotation Angle 0~360° ;Resolution: 1 or 0.01°，Accuracy 6’ |
|||
|
Digital Readout |
DP400 Multifunction colorful LCD digital readout |
||
| Illumination |
Contour Illumination：3.2V/10W LED Surface Illumination：3.2V/10W LED |
||
| Working Environment |
Temp 20℃±5℃，Humidity 40％－70％RH |
||
|
Power Supply |
AC110V/60Hz; 220V/50Hz,150W |
||
|
Cold-air Blowing System |
3-axis Powerful Fan |
||
|
Gross/Net Weight |
220/170kg |
220/170kg |
|
Vertical Profile Projector Objective Lens
|
Objective Lens |
10X(Std.) |
20X(Opt.) |
50X(Opt.) |
|
Code# |
512-110 |
512-120 |
512-130 |
|
Field of View |
Φ40mm |
Φ20mm |
Φ8mm |
|
Distance |
80mm |
67.7mm |
51.4mm |
Vertical Profile Projector Standard Delivery
| Product Name | Code# | Product Name | Code# |
| Digital Readout DP400 | 510-340 | Mini Printer | 581-901 |
| 10X Objective Lens | 511-110 | Power cable | 581-921 |
| Anti-dust Cover | 511-911 | Screen Clamp Device | 581-341 |
| Warranty Card/ Certification | / | Operation Manual/Packing List | / |
Vertical Profile Projector Optional Accessories
| Product Name | Code# | Product Name | Code# |
| 20X Objective Lens | 511-120 | Swivel Center Support | 581-851 |
| 50X Objective Lens | 511-130 | Holder with Clamp | 581-841 |
| Φ300mm Over-Chart | 581-361 | V-block with Clamp | 581-831 |
| 200mm Reading Scale | 581-211 | Rotary Tables RT1 | 581-511 |
| Working Cupboard | 581-620 | Rotary Tables RT2 | 581-521 |
| Edge Finder SED-300 | 581-301 | Foot Switch ST150 | 581-351 |
