MG400 Desktop Small Robotic Arm
About DOBOT MG400
DOBOT MG400 is a lightweight space-saving desktop robotic arm suitable for diversified manufacturing needs. It is flexible to deploy and easy to use, perfect for small space applications. MG400 is a good fit for automated workbench scenarios in tight workspaces that require fast deployment and changeover.
The Powerful Feature Set of MG400
Space Saving, Light, and Small
With the footprint dimension of 190mm × 190mm, MG400 can fit in any production environment smaller than one piece of A4 paper and free up more space in the plant for production. It is the perfect fit for repeating lightweight tasks and automated workbench scenarios in tight workspaces. The compact desktop collaborative robot weighs only 8kg but has a payload up to 750g.
Simplicity Means Productivity
Simplicity is integrated into a robot’s dimension. The robotic arm’s elegant design is a solid foundation for easy robotics development. MG400 emulates human actions using a hand-guided teaching pendant. Our technicians made it easy for you; drag and move it to gain knowledge.
Great Boost to Automation
By replacing the highly repetitive and standardized procedures, MG400 optimizes desktop human-collaborative work and helps businesses cut costs. All these measures boost efficiency and quality.
Rich Programming Choice
MG400 offers a wide selection of programming options, including trajectory reproduction, graphical programming, and Lua script programming. An intuitive programming interface and a guided-interactive design lower the barriers to robot applications.
SPECIFICATIONS
| DOBOT MG400 |
| DT-MG-P4R07-01l |
| 4 |
| 500g (Max 750g) |
| 440mm |
| ±0.05mm |
| ±160° |
| -25°~85° |
| -25°~105° |
| -180°~180° |
| 300° /s |
| 300° /s |
| 300° /s |
| 300° /s |
| 100~240V AC, 50/60 Hz |
| 48V |
| 150W |
| TCP/IP, Modbus TCP |
| Counter |
| 8kg |
| 190mm × 190mm |
| 0 ℃ ~40 ℃ |
| DobotStudio 2020, SCStudio |
