Enameled Round Copper Wire

Short Description:

Thermal class: 120℃,130℃, 155℃,180℃, 200℃,220℃

Dimension: 3.25-7.35; AWG 1-10 copper wire

Enamelled round copper wire is defined as round copper wire used in electrical or wire work that has been painted with matching insulating paints after baking, in compliance with customer requirements, based on a particular mold drawing, and having the required compatibility and temperature resistance index of insulating paint. Transformers, generators, motors, reactors, and other electrical equipment can all be wound with this device.

Send email to us Download as PDF

Product Detail

Product Tags

product details

Product IntroductionHeg

Enamelled round copper wire

Dimension: 3.25- 7.35mm

Enamel Insulation: polyester, polyesterimide, polyamide, modified polyesterimide, polyamideimide

Conductor : copper rod

120 grade polyester enameled round copper wire

130 grade polyester enameled round copper wire

155 grade polyester enameled round copper wire

180 grade polyesterimide / polyamide enameled round copper wire

200 grade polyester or polyester imide/polyamide imide enameled round copper wire

220 grade polyester or polyester imide/polyamide imide enameled round copper wire

If you would like to test a different kind of enameled wire, please contact us.

Product ParametersHeg

Product Name	QQ-120	QZ-130	QZG-155	QZY-180	Q(ZY/XY)-200	QY-220
Standard	QQ-120	GB/T6109.7 GB/T23312.3	60317-16 GB/T6109.2 GB/T23312.4	MW30 60317-18 GB/T6109.5 GB/T23312.5	MW35 60317-13 GB/T6109.20 GB/T23312.7	QY-220
Temperature Class	120℃	130℃	155℃	180℃	200℃	220℃
Paint	Polyvinyl Acetal	Polyester	Modified Polyester	Polyesterimide	Polyesterimide	Polyesterimide
Production Range	0.1-6.5mm	0.1-6.5mm	0.1-6.5mm	0.1-6.5mm	0.1-6.5mm	0.1-6.5mm
Film Thickness	IEC60317-0-1 GB6108.2-85	IEC60317-0-1 GB6108.2-85	IEC60317-0-1 GB6108.2-85	IEC60317-0-1 GB6108.2-85	IEC60317-0-1 GB6108.2-85	IEC60317-0-1 GB6108.2-85
Thermal Shock	300℃	155℃	175℃	200℃	155℃	155℃

Enamelled round copper wire guage (awg/swg 1-10 copper wire is hot sale magnet wire)

Wire gauge	SWG			AWG
	INCH	MM	SQMM	INCH	MM	SQMM
1	0.3	7.62	45.603	0.289	7.35	42.429
2	0.276	7.01	38.594	0.258	6.54	33.592
3	0.252	6.4	32.169	0.229	5.83	26.694
4	0.232	5.89	27.247	0.204	5.19	21.155
5	0.212	5.38	22.732	0.182	4.62	16.763
6	0.192	4.88	18.703	0.162	4.11	13.267
7	0.176	4.47	15.692	0.144	3.66	10.52
8	0.16	4.06	12.946	0.128	3.26	8.346
9	0.144	3.66	10.52	0.114	2.9	6.605
10	0.128	3.25	8.295	0.102	2.59	5.268
