AZ Series Resilient seated NRS gate valve
Description:
AZ Series Resilient seated NRS gate valve is a wedge gate valve and Non-rising stem type, and suitable for use with water and neutral liquids (sewage) . The non-rising stem design ensures the stem thread is adequately lubricated by the water passing through the valve.
Characteristic:
-On-line replacement of top seal: Easy installation and maintenance.
-Integral rubber-clad disc: The ductile iron frame work is thermal-clad integrally with high performance rubber. Ensuring tight seal and rust prevention.
-Integrated brass nut: By means of special casting process. the brass stem nut is integrated with the disc with secure connection, thus the products is safe and reliable.
-Flat-bottom seat: The sealing surface of the body is flat without hollow, avoiding any dirt deposit.
Application:
Water supply system, water treatment, sewage disposal, food processing, fire protection system, natural gas, liquefied gas system etc.
Dimensions:
| Size mm (inch) | D1 | D2 | D0 | H | L | b | N-Φd | Weight (kg) |
| 65(2.5″) | 139.7(5.5) | 178(7) | 160(6.3) | 256(10.08 | 190.5(7.5) | 17.53(0.69) | 4-19(0.75) | 15 |
| 80(3″) | 152.4(6_) | 190.5(7.5) | 180(7.09) | 275(10.83) | 203.2(8) | 19.05(0.75) | 4-19(0.75) | 20.22 |
| 100(4″) | 190.5(7.5) | 228.6(9) | 200(7.87) | 310(12.2) | 228.6(9) | 23.88(0.94) | 8-19(0.75) | 30.5 |
| 150(6″) | 241.3(9.5) | 279.4(11) | 251(9.88) | 408(16.06) | 266.7(10.5) | 25.4(1) | 8-22(0.88) | 53.75 |
| 200(8″) | 298.5(11.75) | 342.9(13.5) | 286(11.26) | 512(20.16) | 292.1(11.5) | 28.45(1.12) | 8-22(0.88) | 86.33 |
| 250(10″) | 362(14.252) | 406.4(16) | 316(12.441) | 606(23.858) | 330.2(13) | 30.23(1.19) | 12-25.4(1) | 133.33 |
| 300(12″) | 431.8(17) | 482.6(19) | 356(14.06) | 716(28.189) | 355.6(14) | 31.75(1.25) | 12-25.4(1) | 319 |
