1. Use and Features:
1. This machine is suitable for the same size of the non-metal coil with the width less than 600mm.
2. The machine is controlled by PLC, with the display screen (text display) operation, and has an automatic feeding device, which is accurate in positioning and saves raw materials.
3. Adopt draulic die-cutting device, four-column guide, high pressure, accurate die-cutting, smooth operation.
4. Belt transport, material input from one end of the machine, die cut, indentation from the other end output, workers only need to pick up the finished material on the conveyor belt, greatly improve the production efficiency.
5. The operating surface of the cutting area is equipped with photoelectric protection device to ensure the safety of the operators.
6. The discharging part of the machine is equipped with tension control device to keep the material tight during transportation and prevent the material from deviation.
7. Special specifications can be customized
2. Main technical parameters:
model
HST150
HST300
HST400
Maximum cutting force
150KN
300KN
400KN
Maximum cut width
400mm
500mm
600mm
Cut the area
400*400mm
500*500mm
600*600mm
Power of main motor
3KW
5.5KW
7.5KW
Machine weight (approx.)
2000kg
3000kg
3500kg
