5G N78 Bandpass Cavity Filter Operating from 3400-3700MHz JX-CF1-3400M3700M-50N
Description
N78 Low Insertion Loss Bandpass Cavity Filter Operating from 3400-3700MHz
Cavity filter JX-CF1-3400M3700M-50N is one kind of bandpass filter for 5G solution. Its frequency covers from 3400-3700MHz with the pass band of 300MHz, which features the insertion loss of less than 1dB, ripple below 1dB, the return loss of over 15dB, high rejection over 50dB @ DC-3200MHz & 3900-6000MHz, input power under 100w. It connects with N female, small volume measured 95mm x 50mm x 22mm in silver color.
For 5G filters, there are more bandpass filters which can be customized by according to the definition. As promised, all the RF passive components from have 3 years warranty.
Paramete
| Parameter |
Specification |
| Frequency range |
3400-3700MHz |
| Return loss |
≥15dB |
| Insertion loss |
≤1.0dB |
| Ripple |
≤1.0dB |
| Rejection |
≥50dB @ DC-3200MHz |
|
≥50dB @ 3900-6000MHz |
|
| Input power (continuous/peak) |
50W/100W |
| Impedance |
50Ω |
Custom RF Passive Components
Only 3 Steps to Solve Your Problem of RF Passive Component
1. Defining the parameter by you.
2. Offering the proposal for confirmation by .
3. Producing the prototype for trial by .
