DC Output
| Rated output |
1000V/22A |
| Constant power voltage range |
22kW (300V~1000V) |
| Output voltage range |
200V~1000V |
| Output current range |
0~73.3A |
| Output over voltage protection |
1010±5V |
| Output under voltage alarm constant |
50V±5V |
| Short circuit protection |
Short circuit retraction constant current output is adopted in case of short circuit, which can be recovered automatically |
| Voltage stabilized accuracy |
≤±0.5% |
| Current stabilizing accuracy |
≤±1% |
| Max. startup overshoot |
≤±1% |
| Startup time |
3s≤t≤8s |
| Efficiency |
Highest efficiency>96.5%, rated efficiency>95% |
Communication & Alarm
| Communication |
CAN |
| Alarm and status |
CAN bus communication LED display |
Operating Environment
| Operating temperature |
-20℃~55℃, derates from 55℃, shut down automatically over 75℃ |
| Storage temperature |
- 40°C~85°C |
| Humidity |
95% RH, without condensation |
| atmospheric pressure/Altitude |
≤2000m， 2000~4000m derates to 70% (55℃) |
- Physical Characteristics
| Acoustic Noise |
＜60dB, Mute mode ≤ 55dB |
| Cooling |
Indepedent airduct cooling |
| Dimension |
362.5mm (W) *91mm (H) *637mm (D) |
| Weight |
<25kg |
